VSM30-X

Extra Long Travel Modular UHV Compatible Stage

From £5,316.00 excl. VAT and transportation cost$7,055.00 excl. VAT and transportation cost€6,450.00 excl. VAT and transportation cost

Linear translation stage for ultra high vacuum applications. Travel ranges from 500 mm and can support loads up to 40 kg.

Compatible with AML's vacuum stage mounting brackets. These can be used to create multi-axis mechanisms with VSM stages.

Overview

  • Standard travels from 500 mm
  • 5 µm resolution (1 µm for option HR)
  • Maximum speed 25 mm/s (5 mm/s for option HR)
  • Suitable for use to 1 x 10-10 mBar
  • Directly stackable with VSM23 and VSM17 stages
  • Lightweight design using UHV-prepared aluminium construction as standard
  • Encoder options available
  • Bakeable to 150°C

Limit switches included as standard.

Order Code Description
Price
VSM30-X-500 500 mm travel, 5 µm resolution5,316.007,055.006,450.00
VSM30-X-600 600 mm travel, 5 µm resolutionContact Us
VSM30-X-700 700 mm travel, 5 µm resolutionContact Us
VSM30-X-800 800 mm travel, 5 µm resolutionContact Us
VSM30-X-900 900 mm travel, 5 µm resolutionContact Us
VSM30-X-1000 1,000 mm travel, 5 µm resolutionContact Us
