UHV Wiring Accessories

Cable clamps and terminal blocks for in-vacuum cabling.

From £49.00 excl. VAT and transportation cost$65.00 excl. VAT and transportation cost€60.00 excl. VAT and transportation cost

Cable clamps and terminal blocks for in-vacuum cabling.

Overview

  • PEEK wiring bushes used in situations where a 'P' clip would be used in air
  • PEEK terminal block. 6-way
  • Stainless steel barrel connectors & grub screws
  • Bakeable to 250°C
Order Code Description
Price
PWB PEEK wiring bushes x 479.00105.0095.00
VTB6 PEEK Terminal Block, 6-way49.0065.0060.00
BC1.5 Barrel Connectors 1.5 mm Bore, pack of 1056.0075.0070.00
